Designing a Real-Time Chat System (Slack-style)

28 Jul 2026

This is a write-up of a system design exercise I worked through for real-time communication between users, modeled loosely on Slack. It covers the requirements, the evolution from polling to WebSockets, how to scale WebSocket connections across multiple servers, and the database schema.

To keep the core design easy to reason about, I’ve deliberately scoped out multi-device support and strict message ordering guarantees — these are called out as improvements at the end rather than folded into the main design.

Requirements

  • Multiple users, multiple channels
  • Users can DM each other or message in a channel
  • Real-time chat — messages should be delivered live, not on refresh
  • Historical messages can be scrolled through (pagination)

Architecture at a Glance

Before diving into the individual pieces, here’s the end state we’re building toward: clients hold a persistent WebSocket connection to one of several WS servers, a discovery layer tracks which server each user is on, and a Chat Service is the single source of truth for persistence.

flowchart LR
    A[User A] -- WebSocket --> WS1[WS Server 1]
    B[User B] -- WebSocket --> WS2[WS Server 2]
    C[User C] -- WebSocket --> WS2

    WS1 <--> DS[Discovery Service<br/>user_id to server mapping]
    WS2 <--> DS

    WS1 <--> MB[(Message Broker<br/>Pub/Sub)]
    WS2 <--> MB

    MB --> CS[Chat Service]
    CS --> DB[(Database)]

    style DS fill:#f9f0d9,stroke:#c9a227
    style MB fill:#dde8f5,stroke:#4a7ab5
    style DB fill:#e2f0e2,stroke:#4a8a4a
  • WS Servers hold the actual live connections and know nothing about routing — they just push to whichever local sockets they’re told to.
  • Discovery Service is the “phone book”: given a user_id, it tells you which WS server (if any) that user is currently connected to.
  • Message Broker is the pub/sub layer that lets a message published on one WS server’s side reach a subscriber connected to a different WS server.
  • Chat Service + DB is the durability layer — every message is persisted here regardless of whether anyone was online to receive it live.

Data Model

Four core entities:

User
  id
  name

Message
  id
  from
  channel_id

Channel
  id
  name
  type: direct / group

ChannelUserMapping
  id
  channel_id
  user_id

A few useful queries this schema supports directly:

-- messages in a channel
SELECT * FROM messages WHERE channel_id = ?

-- users in a channel
SELECT DISTINCT(user_id) FROM channel_user_mapping WHERE channel_id = ?

Member joins/leaves are handled as separate operations against ChannelUserMapping, rather than being baked into the channel or message tables.

Getting to Real-Time: Three Approaches

1. Short Polling

The simplest approach: the client repeatedly calls an endpoint like GET /messages?channel_id=?&from=?, and the server returns new messages if any exist, or an empty response otherwise.

Problem: the client is guessing when to ask. Poll too infrequently and messages feel delayed; poll too frequently and you’re hammering the server with mostly-empty responses. It’s simple but not truly real-time.

sequenceDiagram
    participant B as User B
    participant S as Server

    loop every few seconds
        B->>S: GET /messages?channel_id=X&from=Y
        S-->>B: [] (no new messages)
    end
    Note over B,S: eventually...
    B->>S: GET /messages?channel_id=X&from=Y
    S-->>B: [new message]

2. Long Polling

The client keeps the connection open, and the server only responds once a new message actually shows up (or a timeout elapses, after which the client reopens the connection).

Problem: this is still fundamentally client-initiated. The server can only respond — it can’t push new data on a connection unless the client asked first. That still doesn’t give you real bidirectional, low-latency communication, and the connection churn (constantly closing and reopening) is wasteful.

sequenceDiagram
    participant B as User B
    participant S as Server

    B->>S: GET /messages?channel_id=X&from=Y
    Note over S: connection held open...
    Note over S: new message arrives
    S-->>B: [new message]
    B->>S: GET /messages?channel_id=X&from=Y (reopen)
    Note over S: connection held open again...

3. WebSockets

WebSockets open a persistent, bidirectional connection between the client and server. Once established, either side can send data at any time. This is the right building block for real-time chat — it’s the actual mechanism underneath both Slack and most modern chat apps. (Server-Sent Events were also considered, but ruled out since they’re server-to-client only — the client still needs a separate channel to send messages.)

sequenceDiagram
    participant B as User B
    participant S as Server

    B->>S: WebSocket handshake (upgrade)
    S-->>B: connection established (persistent)
    Note over B,S: connection stays open
    S->>B: push: new message (server-initiated!)
    B->>S: send: new message

Scaling WebSocket Connections

A single server can only hold so many concurrent open socket connections. If you have many users, you need multiple servers holding connections, which introduces a new problem: if user A is connected to server 1 and sends a message to user B, who is connected to server 2 — how does server 1 know where to deliver it?

Discovery Service

The fix is a discovery service that tracks which server each user’s active WebSocket connection lives on:

  • When a client first loads the app, it registers with the discovery service, recording which WS server it has an open connection to.
  • When user A sends a message, it’s routed to a Chat Service, which persists it to the DB and also asks the discovery service where user B is connected.
  • If B has an active connection, the message is routed to the correct WS server and pushed down B’s socket in real time.
  • If B isn’t connected anywhere, the message is just persisted — B will see it next time they load the channel or reconnect.
sequenceDiagram
    participant A as User A
    participant WS1 as WS Server 1
    participant CS as Chat Service
    participant DS as Discovery Service
    participant WS2 as WS Server 2
    participant B as User B

    A->>WS1: send message to B
    WS1->>CS: forward message
    CS->>CS: persist to DB
    CS->>DS: where is B connected?
    DS-->>CS: WS Server 2
    CS->>WS2: deliver message
    WS2->>B: push message (live)

Channel / Group Fan-out

For channels (as opposed to 1:1 DMs), the same idea extends via pub/sub: each WS server subscribes to the channels its connected users are members of. When a message is published to a channel, it’s fanned out to every WS server that has at least one relevant subscriber, and each of those servers pushes it to its own connected sockets.

This is fan-out-on-write: the fan-out work happens at message-send time, not at read time. It’s the standard approach for chat systems at Slack’s scale (as opposed to fan-out-on-read, which is more common for large, algorithmic feeds).

flowchart TB
    A[User A sends to Channel] --> CS[Chat Service]
    CS -->|1. persist| DB[(Database)]
    CS -->|2. publish to channel topic| MB[(Message Broker)]

    MB -->|subscribed| WS1[WS Server 1]
    MB -->|subscribed| WS2[WS Server 2]

    WS1 --> B[User B]
    WS1 --> C[User C]
    WS2 --> D[User D]

    style CS fill:#dde8f5,stroke:#4a7ab5
    style MB fill:#f9f0d9,stroke:#c9a227

Note the fan-out is per WS server that has relevant subscribers, not per individual user — if 50 channel members happen to be connected to the same WS server, that’s a single publish to that server, which then pushes to its 50 local sockets.

Avoiding Duplicate Persistence

One subtlety: a message needs to be persisted (Chat Service → DB) and also delivered live (via the WS/pub-sub path) — these are two different concerns and should be handled by two different components, not conflated:

  • Chat Service is the single source of truth for persistence — it writes every message to the DB exactly once.
  • The WS/pub-sub queue is purely for real-time fan-out to connected clients and should not also be treated as a persistence layer. Keeping these responsibilities separate avoids double-writes and keeps recovery logic simple — if delivery fails, the message is still safely in the DB and will show up on next fetch.

Handling Scale: Sharded Discovery Services

If the number of users is large enough that a single discovery service (or a single set of WS servers) can’t hold all the connection state, you shard it — e.g., partitioning users across DiscoveryService1, DiscoveryService2, etc. Each shard registers itself as a subscriber to the relevant channels / topics in a shared message broker (SQS/Redis/Kafka-like), so that a message originating on one shard can still be routed to a user connected via a different shard.

flowchart LR
    A[User A] --> DS1[Discovery Service 1]
    B[User B] --> DS1
    C[User C] --> DS2[Discovery Service 2]
    D[User D] --> DS2

    DS1 <--> MB[(Shared Message Broker<br/>topics = channels)]
    DS2 <--> MB

    style MB fill:#f9f0d9,stroke:#c9a227

Each discovery service shard subscribes to the broker on behalf of its own users’ channels, so a message published by a user on DiscoveryService1 can still reach a subscriber whose connection lives on DiscoveryService2.

Putting It Together (End-to-End Flow)

  1. Client loads the app → registers its WebSocket connection with the discovery service.
  2. User A sends “Hi” to a channel → goes to the discovery service / message-fan-out layer.
  3. It checks which channel members have active connections and pushes the message to the WS servers those connections live on.
  4. In parallel, the message is sent to a queue → picked up by a worker → persisted to the DB.
  5. Any client without an active connection simply reads the message from the DB the next time they open the channel.

Afterthoughts / Future Improvements

These were intentionally left out of the core design to keep it focused, but are worth calling out as natural next steps:

  • Multi-device support. Users are often connected from more than one device at once (phone + laptop). The discovery mapping would need to go from user_id → single connection to user_id → set of connections, and delivery/read-state would need to account for multiple active sessions per user.

  • Strict message ordering guarantees. With multiple WS servers and a pub/sub fan-out layer in between, messages sent close together from different servers aren’t guaranteed to arrive or be persisted in send order. A more complete design would assign each channel’s messages a monotonically increasing sequence number at write time (e.g., by serializing writes per channel, or using a partitioned log like Kafka keyed by channel_id), and have clients render/order by that sequence number rather than by arrival time.

  • Offline push notifications for users with no active connection at all.

  • Pagination strategy for scrolling through history — cursor-based pagination on (channel_id, created_at) rather than naive SELECT *.

  • Presence and typing indicators, which piggyback on the same connection infrastructure but weren’t part of the core requirements here.
